SolarGard® Xenith IR® Ceramic Film

SolarGard® Xenith IR® Ceramic Film Series "Auto & Marine".

Xenith IR® Ceramic Film Series offers discerning drivers our highest level of driving comfort and solar protection. Through a proprietary technology that leverages the most advanced ceramic materials available today, this new line introduces Solar Gard’s coolest interior temperature yet, clear transmission of cellular and other data signals, and a true black hue that enhances the look of every vehicle exterior. Additionally, XenithIR blocks more than 99% of harmful UV rays to shield passengers from skin damage and high-end interior furnishings from premature fading.

FAST FACTS:

Next-generation ceramic technology rejects up to 93% of infrared rays*
Total Solar Energy Rejection (TSER) of up to 64%
Blocks more than 99% of harmful UV rays to protect passengers and vehicle interiors
Signal-friendly construction won’t interfere with mobile phones, GPS navigation, satellite radio, and other electronic devices
Helps keep shattered glass together for increased safety
Rich black color that complements all exteriors
Available in a wide range of shades to accommodate any driver’s preference and minimize glare

*Measured with Solar Spectrum Transmission Meter

Warranty:

Color-stable
Limited lifetime transferable
Replacement product and labor
National dealer network

See actual warranty certificate for details and coverage activation.

Performance Results

Specification	XenithIR 5	XenithIR 15	XenithIR 30	XenithIR 35	XenithIR 45	XenithIR 55	XenithIR 70	XenithIR 80
Visible light transmittance %	5%	15%	30%	38%	45%	56%	67%	76%
Visible light reflectance (exterior) %	5%	5%	5%	6%	6%	7%	8%	8%
Visible light transmittance on auto glass %	4%	13%	25%	32%	38%	47%	57%	64%
UV light blocked (300 to 380 nm) %	>99%	>99%	>99%	>99%	>99%	>99%	>99%	>99%
Total solar energy rejected %	64%	63%	60%	59%	56%	51%	50%	44%
SIRR - Selective Infrared energy rejected %1	91%	93%	93%	93%	91%	91%	91%	82%
IRER - Infrared energy rejected %2	64%	65%	66%	65%	65%	63%	64%	61%

Performance Notes:

Performance results are calculated using NFRC methodology and LBNL Window software, and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and are subject to normal manufacturing variances.
Performance results based on film applied to ¼” (6mm) clear glass and a representative automotive glass with a base visible light transmission of 75%. Due to variations in glass performance, these values should not be used to comply with local tinting laws.

Definitions:

[1] SELECTIVE INFRARED REJECTION (SIRR) The percent of "film only" transmitted infrared energy (780 nm to 1700 nm) measured using the Solar Spectrum transmission meter (model # SS2450). The higher the number, the less infrared directly transmitted.
[2] INFRARED ENERGY REJECTION (IRER) The percent of infrared energy (780 nm to 2500 nm) that is directly reflected and absorbed and radiated outwards. Calculated as 1 – SHGC (780 nm to 2500 nm) using Lawrence Berkeley National Laboratory (LBNL) Window software and NFRC 200 solar spectrum from 780 nm to 2500 nm. The higher the number, the more infrared energy reflected and absorbed and released outwards. IRER is the endorsed calculation method of IWFA.
